Kaitaer hand Lever Hoist Series Products

1、Product Characteristics analysis

1)lever hoist capacity range from 0.75ton to 9 ton.

2)Ergonomic handle design so that the hoist is easy to operate,product suitable for all application.

3)Suspension and load hooks are made of alloy steel 35CRMO,heat treated and fitted with heavy duty safety latches,fitting groove and inspection points.

4)Machined chain sprocket and gears provide smoother,more efficient operation.

5)Hook with safety latch securely can rotate freely 360 degrees.

6)Gears are made of 20CRMNTI,material which ensures toughness and better strength.

7)Fitted with high strength grade 80 alloy steel load chain with galvanized finish for corrosion resistance.

8)Load chain marked with T8 marks as per EN 818-7.

9)Heavy duty guide rollers for avoiding slippage of load chain.

10)Nylon pull ring.

11)All hoists tested at 1.5 times of WLL/

2、Product Introduction and application:

1. Lever block is a kind of highly efficient and versatile hand operate hoisting appliance.It is particularly used in the narrow places,the open air and overhead places for pulling and stretching work at any angle.

2. The lever block is using in safety,reliable and durable.

3. The lever block is excellent performance,easy operation and convenience maintenance.

4. The lever block is small volume,weight light and portable in size.

5. The lever block is high efficiency ,fast lifting and light hand pull.

6. There are advanced structure and attractive appearance of lever chain block.
